LYSAGHT BONDEK®
Product Description and Features
LYSAGHT BONDEK® is a highly efficient, versatile and robust formwork, reinforcement and ceiling system for concrete slabs. It is a profile steel sheeting widely accepted by the building and construction industry to offer efficiency and speed of construction.
- Excellent spanning capacities for greater strength and less deflection
- Acts as permanent formwork with minimal propping and no stripping of formwork is required
- Fast and easy to install (590mm wide) with less handling required
- Works as composite slab saving on concrete and reinforcement costs
- Ribs at 200mm centres creating a safe working platform with slip resistant embossments
- Advanced design for fire resistance
- New BONDEK® software gives added flexibility and ease of design
- Increased unsupported spans of BONDEK® sheeting
- Backed by a BlueScope Steel warranty
- Nationwide technical support
Note:
- Design & detailing should be carried out by a qualified structural engineer
Brochures
LYSAGHT BONDEK® Users Guide
- Download Now (1979 KB)
LYSAGHT BONDEK® Performance Enhancements
- Download Now (266 KB)
LYSAGHT BONDEK® CAD File
- Download Now (75 KB)
This search will find the ten closest suppliers for the location you enter, for the selected product. Fill in each of the fields below, then click "SEARCH"
Please note this locator only contains suppliers in AUSTRALIA. If you need suppliers in other countries please contact your local BlueScope Steel office.
Fields marked with * are required
You may choose to Search for Supplier by Name
Spanning Tables
Span tables for LYSAGHT BONDEK® can be found in our Users Guide: Download LYSAGHT BONDEK® Users Guide (703 KB)
Professional members of our Website can download the full Design Manual from: LYSAGHT BONDEK® 2008 Design and Construction Guide and Software
Tolerance
Length: +0mm, -10mm
Specification
LYSAGHT BONDEK® profiled steel sheeting is roll-formed from hot dipped, zinc-coated, hi-tensile, steel strip, in base metal thicknesses (BMT) of 0.60, 0.75, 0.90 and 1.0mm. The steel strip conforms to AS1397 grade G550, Z350.
0.9mm thickness is available for projects by special order.
Pre-painted BRITEWITE® soffit is also available on enquiry.
Physical Properties
| Thickness (mm) | Mass | Yield Strength MPa | Coverage m2/t |
|
|---|---|---|---|---|
| kg/m2 | kg/m | |||
| 0.60 0.75 0.90 1.00 |
8.52 10.50 12.48 13.79 |
5.03 6.20 7.36 8.14 |
550 550 550 550 |
117.31 95.24 80.16 72.50 |
Schematic
Availability
LYSAGHT BONDEK® is available in all states.
FAQs
How far can LYSAGHT BONDEK® span as formwork?
By span we take the distance between centres of supports. There are 3 major considerations when establishing span distance:
1. What slab thickness is being used?
2. What gauge of LYSAGHT BONDEK® is being used?
3. Is the underside of the slab going to be visible or not?
When these considerations are known, the tables in our BONDEK® Users Guide can be used effectively to design BONDEK® formwork. Download LYSAGHT BONDEK® Users Guide (815 KB)
Can LYSAGHT BONDEK® be fire-rated?
As a composite slab, LYSAGHT BONDEK® can be fire-rated up to 4 hours, without the use of a fire spray on the underside of the sheeting.
What type of building applications can LYSAGHT BONDEK® be used in?
LYSAGHT BONDEK® can be used as formwork and as a reinforcement in composite slabs. It can be used in a wide range of building construction including steel, concrete and masonry framing system with a minimum ground clearance of 450mm. It is typically designed as a one-way slab.
Design
Spanning Tables
Span tables for LYSAGHT BONDEK® can be found in our Users Guide: Download LYSAGHT BONDEK® Users Guide (703 KB)
Professional members of our Website can download the full Design Manual from: LYSAGHT BONDEK® 2008 Design and Construction Guide and Software
Specification
Tolerance
Length: +0mm, -10mm
Specification
LYSAGHT BONDEK® profiled steel sheeting is roll-formed from hot dipped, zinc-coated, hi-tensile, steel strip, in base metal thicknesses (BMT) of 0.60, 0.75, 0.90 and 1.0mm. The steel strip conforms to AS1397 grade G550, Z350.
0.9mm thickness is available for projects by special order.
Pre-painted BRITEWITE® soffit is also available on enquiry.
Physical Properties
| Thickness (mm) | Mass | Yield Strength MPa | Coverage m2/t |
|
|---|---|---|---|---|
| kg/m2 | kg/m | |||
| 0.60 0.75 0.90 1.00 |
8.52 10.50 12.48 13.79 |
5.03 6.20 7.36 8.14 |
550 550 550 550 |
117.31 95.24 80.16 72.50 |
Schematic
Availability
Availability
LYSAGHT BONDEK® is available in all states.
