LYSAGHT MINI ORB®

Product Description and Features

LYSAGHT MINI ORB® is a mini-corrugated profile which is suitable for use in interior or exterior applications on straight or curved surfaces. It has the same traditional shape as LYSAGHT CUSTOM ORB® but on a much reduced scale.  Its subtle profile is a perfect complement to other LYSAGHT® claddings to provide a "contrasting" surface as an accent feature. It is primarily used for decorative finishes on walls, ceilings and soffit linings; feature walls and partitions; and screens and small awnings not subject to any foot traffic.

  • Able to be used for both straight and curved applications
  • Can be used with the corrugations running vertically or horizontally
  • Can be laid flat, pre-curved, or spring-curved for increased versatility
  • Available in a wide variety of COLORBOND® steel colours and ZINCALUME® steel
Note:

Brochures

LYSAGHT® Walling Solutions

Lysaght

Important product update

Release date 1 August 2013

Following BlueScope’s launch of next generation ZINCALUME® steel, Lysaght has commenced supplying our unpainted product range using next generation ZINCALUME® steel AM125 where previously original ZINCALUME® steel AZ150 would have been used . Next generation ZINCALUME® steel AM125 is guaranteed by BlueScope to meet AS1397 and the ‘deemed to satisfy’ requirements of the Building Code of Australia for applications such as roofing and walling.

We are currently updating the Lysaght website and brochures to reflect this change. In the meantime, where the enclosed literature makes reference to ZINCALUME® the reader should note that this may refer to the previous version of the product.

Due to its increased corrosion performance compared to original ZINCALUME® steel AZ150, roofing applications made from next generation ZINCALUME® steel AM125 will be backed by an improved warranty of up to 36 years.*

*For full terms and conditions and to determine the eligibility of your project for the warranty visit www.bluescopesteel.com.au/warranties or call BlueScope on 1800 022 999

For further information on next generation ZINCALUME® steel visit http://www.nextgenzincalume.com.au.

Download Now

LYSAGHT® Roof & Wall Flashing - Architectural Detailing Manual

LYSAGHT MINI ORB® CAD Drawing File

This search will find the ten closest suppliers for the location you enter, for the selected product. Fill in each of the fields below, then click "SEARCH"

Please note this locator only contains suppliers in AUSTRALIA. If you need suppliers in other countries please contact your local BlueScope Steel office.

Fields marked with * are required

Availability

NSW/
ACT
VICTASQLDNTSAWA
Avail. By Enquiry* Avail. Avail. Avail. Avail. Avail.

*Please contact our sales office on 13 30 38 for availability.

Colour Range

LYSAGHT MINI ORB® is available in the standard range of COLORBOND® steel colours and in unpainted ZINCALUME® steel.

Please check with your local supplier regarding specific colour availability for this product.

COLORBOND® steel colours

Lengths

Sheets are supplied custom cut.

Tolerances

Length: +5mm, -5mm
Width: +2mm, -2mm

Material Specification

  • Next generation ZINCALUME® aluminium/zinc/ magnesium alloy coated steel complies with AS 1397:2011 G550, AM125 (550 MPa minimum yield stress, 125 g/m2 minimum coating mass)
  • COLORBOND® is prepainted steel for exterior roofing and walling. It is the most widely used. The painting complies with AS/NZS 2728:2013 and the steel base is an aluminium/zinc alloy-coated steel complying with AS 1397:2011. Minimum yield strength is G550 (550MPa). Minimum coating mass is AM100 (100g/m2)
  • COLORBOND® Metallic is prepainted steel for superior aesthetic qualities displaying a metallic sheen.
  • COLORBOND® Ultra is prepainted steel for severe coastal or industrial environments (generally within about 100-200 metres of the source). The painting complies with AS/NZS 2728:2013 and the steel base is an aluminium/zinc alloycoated steel complying with AS 1397:2011. Minimum yield strength is G550 (550MPa). Minimum coating mass is AM150 (150g/m2)
  • COLORBOND® Stainless is a pre-painted steel for severe coastal or industrial environments. The painting complies with AS/NZS 2728:2013 and the steel base is a stainless steel complying with AISI/ASTM Type 430; UNS No. S43000.


Curving information

LYSAGHT MINI ORB® Curving Requirements

MINI ORB® may be spring curved down to 1500mm radius. It is suitable for pre-curving - the minimum radius of curve is 150mm, and the minimum straight length after a curve is 50mm. Some possible profiles are shown on the left.

Pre-curving is subject to enquiry as lead time applies.


Mass - COLORBOND® steel

BMT 0.42mm: 4.04kg/m2
BMT 0.48mm: 4.58kg/m2



Schematic

lysaght-product detail-mini orb schematic



Disclaimer

Span Tables and Capacity & Load Tables

Span Tables and limit state wind pressure capacity table can be viewed in the LYSAGHT Walling Solutions brochure. Download LYSAGHT® Walling Solutions (886 KB)

This information is suitable for use only in areas where a tropical cyclone is unlikely to occur as defined in AS1170.2-2002.



FAQs

Is LYSAGHT MINI ORB® the same product that has been available for many years?

The product was changed in 1997. The old LYSAGHT MINI ORB® product was wider, thicker (thus heavier and more expensive) and manufactured from soft steel. The older product was also limited to a maximum length of 3000mm.


Availability

Availability

NSW/
ACT
VICTASQLDNTSAWA
Avail. By Enquiry* Avail. Avail. Avail. Avail. Avail.

*Please contact our sales office on 13 30 38 for availability.

Colour Range

LYSAGHT MINI ORB® is available in the standard range of COLORBOND® steel colours and in unpainted ZINCALUME® steel.

Please check with your local supplier regarding specific colour availability for this product.

COLORBOND® steel colours

Specification

Lengths

Sheets are supplied custom cut.

Tolerances

Length: +5mm, -5mm
Width: +2mm, -2mm

Material Specification

  • Next generation ZINCALUME® aluminium/zinc/ magnesium alloy coated steel complies with AS 1397:2011 G550, AM125 (550 MPa minimum yield stress, 125 g/m2 minimum coating mass)
  • COLORBOND® is prepainted steel for exterior roofing and walling. It is the most widely used. The painting complies with AS/NZS 2728:2013 and the steel base is an aluminium/zinc alloy-coated steel complying with AS 1397:2011. Minimum yield strength is G550 (550MPa). Minimum coating mass is AM100 (100g/m2)
  • COLORBOND® Metallic is prepainted steel for superior aesthetic qualities displaying a metallic sheen.
  • COLORBOND® Ultra is prepainted steel for severe coastal or industrial environments (generally within about 100-200 metres of the source). The painting complies with AS/NZS 2728:2013 and the steel base is an aluminium/zinc alloycoated steel complying with AS 1397:2011. Minimum yield strength is G550 (550MPa). Minimum coating mass is AM150 (150g/m2)
  • COLORBOND® Stainless is a pre-painted steel for severe coastal or industrial environments. The painting complies with AS/NZS 2728:2013 and the steel base is a stainless steel complying with AISI/ASTM Type 430; UNS No. S43000.


Curving information

LYSAGHT MINI ORB® Curving Requirements

MINI ORB® may be spring curved down to 1500mm radius. It is suitable for pre-curving - the minimum radius of curve is 150mm, and the minimum straight length after a curve is 50mm. Some possible profiles are shown on the left.

Pre-curving is subject to enquiry as lead time applies.


Mass - COLORBOND® steel

BMT 0.42mm: 4.04kg/m2
BMT 0.48mm: 4.58kg/m2



Schematic

lysaght-product detail-mini orb schematic



Disclaimer

Design

Span Tables and Capacity & Load Tables

Span Tables and limit state wind pressure capacity table can be viewed in the LYSAGHT Walling Solutions brochure. Download LYSAGHT® Walling Solutions (886 KB)

This information is suitable for use only in areas where a tropical cyclone is unlikely to occur as defined in AS1170.2-2002.
